Xtreme's industry-leading 10 year – 5 year – 2 year warranty


  • 20,000 lbs Capacity
  • 45 ft Lift Height
  • 27 ft 4 in Forward Reach
  • 134 hp Tier IV Engine


Increased capacity, while still maintaining excellent jobsite maneuverability.

  • 360° operator visibility Suspension seat
  • Easy service access
  • Protected tilt & extend cylinders Steel hydraulic & fuel tanks Long life Lexan labels Suspended pedals
  • Heavy duty boom chains
  • Large capacity fuel tank
  • Trunnion mounted sway cylinders Melonite pins
  • Standard auxiliary hydraulics Steel dash
  • Center mounted powertrain Long life boom rollers
  • Dual batteries
  • Ductile steel manifold
  • Easy cab mounted grab handles
  • Master disconnect switch
  • Boom lift point
  • Manual lowering valve (cylinders) Large cross section boom
  • Easy tie downs
  • ̋Y ̋ frame handle
  • Heavy duty pre-cleaner
  • Additional high pressure hydraulic filter Steel hood
  • Solid steel plate chassis
  • Rear axle stabilization (RAS)
  • Wider outrigger stance
  • Back up alarm with light
  • Cab step

Additional information

Class Carriage


Capacity Weight

20,000 lbs

Lift Height

45 ft

Forward Reach

27 ft 4 in

Frame Leveling L/R

8 degrees

Machine Weight

46,300 lbs


Deutz 3.6L 134 hp (Tier 4F)


Dana 213


Dana T20000

Fuel Capacity

72 gal


17.5 x 25

Hydraulic Flow (per min)

49 gal

Hydraulic Pressure

4,000 psi

Hydraulic Oil Capacity

58 gal

Length to fork face

22 ft 6 in


102 in


8 ft 11 in

Wheel Base

147 in

Ground Clearance

15 in

Turning Radius

15 ft 10 in


Load Chart

XR1055 Load Chart

XR1055 Load Chart

Specifications are subject to change without notice. Photos and diagrams on this website and within downloadable materials are for promotional purposes only. Refer to the appropriate Xtreme Manufacturing operation manual for detailed instructions on proper use, specifications and maintenance of equipment.
